Specification
| Model | NCF-100ZH | NCF-200ZH | NCF-300ZH | NCF-400ZH | NCF-500ZH | NCF-600ZH | NCF-800ZH | NCF-1000ZH | NCF-1300ZH | NCF-1600ZH |
| Metal sheet width | 100mm | 200mm | 300mm | 400mm | 500mm | 600mm | 800mm | 1000mm | 1300mm | 1600mm |
| Zigzag feeding | 50mm | 100mm | 150mm | 200mm | 250mm | 300mm | 400mm | 500mm | 650mm | 800mm |
| Metal sheet thickness | 0.5-6.0mm | |||||||||
| Feeding length per stroke | 0.1-9999.99mm | |||||||||
| Feeding accuracy | ±0.1mm | |||||||||
| Feeding speed | 0-20m/min | |||||||||
| Feeding roller | 4 pieces (Heavy duty) | |||||||||
| Releasing method | by pneumatic cylinder | |||||||||
| Front feeding | YASKAWA servo motor (JAPAN brand) | |||||||||
| Zigzag feeding | YASKAWA servo motor (JAPAN brand) | |||||||||
| PLC | MITSUBISHI (JAPAN brand) | |||||||||
| Human machine interface (HMI) | WEINVIEW (Taiwan brand) | |||||||||
| Other main components | other brands | |||||||||
| Electrical power | 380V, 3 Phase, 50HZ (or else) | |||||||||
